UPS Voltage on vega

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 1500 S attached to vega.

The statistics were last updated Thursday, 26 December, 15:26:29 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.0 V Average Utility:  118.2 V Current Utility:  118.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.0 V Average Utility:  118.3 V Current Utility:  118.7 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  119.9 V Average Utility:  118.6 V Current Utility:  118.8 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  119.7 V Average Utility:  118.8 V Current Utility:  118.4 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
