UPS Load/Charge % on vega

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS NS 1500M2 attached to vega.

The statistics were last updated Thursday, 26 December, 14:46:31 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  29.8 % Average Load  25.7 % Current Load  25.1 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  32.0 % Average Load  25.8 % Current Load  25.5 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  29.2 % Average Load  25.4 % Current Load  25.2 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  27.0 % Average Load  22.8 % Current Load  25.7 %
Max Charge  100.0 % Average Charge  99.9 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
