UPS Voltage on trill

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 700 attached to trill.

The statistics were last updated Thursday, 26 December, 14:41:31 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  123.0 V Average Utility:  122.0 V Current Utility:  123.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  123.0 V Average Utility:  121.9 V Current Utility:  122.3 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  123.0 V Average Utility:  122.0 V Current Utility:  121.9 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  122.6 V Average Utility:  122.0 V Current Utility:  122.0 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
