UPS Load/Charge % on trill

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS Pro 700 attached to trill.

The statistics were last updated Thursday, 26 December, 14:46:31 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  11.0 % Average Load  11.0 % Current Load  11.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  39.4 % Average Load  13.2 % Current Load  11.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  36.2 % Average Load  11.7 % Current Load  11.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  24.4 % Average Load  11.8 % Current Load  11.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
