UPS Load/Charge % on starfire

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS RS 1500MS2 attached to starfire.

The statistics were last updated Thursday, 26 December, 14:36:31 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  23.8 % Average Load  16.0 % Current Load  15.3 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  19.2 % Average Load  15.9 % Current Load  16.4 %
Max Charge  100.0 % Average Charge  99.8 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  23.6 % Average Load  16.0 % Current Load  15.3 %
Max Charge  100.0 % Average Charge  99.9 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  21.9 % Average Load  16.7 % Current Load  15.8 %
Max Charge  100.0 % Average Charge  99.9 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
