UPS Load/Charge % on scimitar

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS Pro 700 attached to scimitar.

The statistics were last updated Thursday, 26 December, 15:26:29 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  39.2 % Average Load  15.4 % Current Load  14.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  24.7 % Average Load  15.2 % Current Load  15.1 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  19.7 % Average Load  15.0 % Current Load  14.6 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  21.8 % Average Load  16.1 % Current Load  15.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
