UPS Voltage on paris

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 1500 S attached to paris.

The statistics were last updated Wednesday, 29 October, 07:56:42 EDT
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  123.0 V Average Utility:  121.3 V Current Utility:  121.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  122.2 V Average Utility:  121.2 V Current Utility:  120.7 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  122.0 V Average Utility:  121.3 V Current Utility:  121.5 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  122.1 V Average Utility:  121.6 V Current Utility:  121.3 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
