UPS Voltage on nat

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 1500 attached to nat.

The statistics were last updated Thursday, 26 December, 15:16:30 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  124.0 V Average Utility:  122.5 V Current Utility:  123.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  123.8 V Average Utility:  122.6 V Current Utility:  122.7 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  124.2 V Average Utility:  122.8 V Current Utility:  122.7 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  124.3 V Average Utility:  123.3 V Current Utility:  122.3 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
