UPS Load/Charge % on evolution

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS Pro 700 attached to evolution.

The statistics were last updated Thursday, 26 December, 15:11:29 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  13.0 % Average Load  11.7 % Current Load  12.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  12.3 % Average Load  11.7 % Current Load  11.7 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  12.3 % Average Load  11.9 % Current Load  11.9 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  12.3 % Average Load  11.7 % Current Load  11.8 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
