UPS Voltage on atlantis

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS 1500 attached to atlantis.

The statistics were last updated Thursday, 17 September, 10:19:36 EDT
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  121.0 V Average Utility:  119.7 V Current Utility:  119.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  121.0 V Average Utility:  119.8 V Current Utility:  119.7 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.5 V Average Utility:  119.6 V Current Utility:  119.6 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.0 V Average Utility:  119.1 V Current Utility:  119.8 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
